Description
Engine
Primary drive: 27:76
Transmission: 6-speed
Cooling: Liquid cooled
Secondary gear ratio: 14:45
Power in KW: 23 kW
Starter: Electric starter
Stroke: 61.2 mm
Bore: 72 mm
CO2 emissions: 63.5 g/km
Compression ratio: 12.4
Displacement: 249.1 cm³
EMS: Bosch EMS with RBW
Design: 1-cylinder, 4-stroke engine
Fuel-mixture generation: Dell`Orto EFI (Throttle body 38mm)
Lubrication: Wet sump
Chassis
Weight (without fuel): 154 kg
Tank capacity (approx.): 13 l
Wheelbase: 1368 mm
Front brake disc diameter: 320 mm
Rear brake disc diameter: 240 mm
Front brake: ByBre, opposed four-piston caliper, brake disc
Rear brake: ByBre, twin-piston, floating caliper, brake disc
Chain: 520 X-Ring
Frame design: Steel trellis frame, powder coated
Front suspension: WP APEX 43
Ground clearance: 180 mm
Handlebar: STEEL
Rear suspension: WP APEX – Monoshock
Seat height: 820 mm
Silencer: Stainless steel silencer with regulated catalytic converter
Steering head: angle66 °
Rear subframe design: Steel trellis frame, powder coated
Suspension travel (front): 150 mm
Suspension travel (rear): 150 mm
Tyre dimensions (front/rear): 1
Wheels: 3 x 17″; 4 x 17″
Wheels: Cast aluminium wheels
